Copper Plating Welded Studs

Copper Plating Welded Studs is a body functional fastener designed specifically for efficient grounding connections, conductive assembly, and welding applications. A high-purity copper layer is uniformly covered on high-strength screws through electroplating process, which combines the mechanical strength of the steel core with the excellent conductivity and weldability of the copper surface.

Send Inquiry

Product Description

Copper Plating Welded Studs from Jinghong manufacturer use high-strength steel as the core, providing the required tensile strength and thread accuracy for standard screws, ensuring a firm and reliable mechanical connection. The dense electroplated copper layer on the surface is key - this layer of copper not only provides excellent conductivity close to pure copper, ensuring smooth current flow and reducing the risk of heating at connection points.

Jinghong Company's standard components are widely used in industries such as light industry, automotive parts, mining machinery parts, household appliances, motors, and paper machinery. We are a private enterprise in the industry, with a large scale and complete range of standard and non-standard parts production varieties. We use advanced production equipment and complete testing processes to create products that satisfy and reassure our customers.

Name	Copper Plating Welded Studs
Material	Carbon Steel
Standards	GB,DIN, BSW, JIS, UNC, UNF, Non-standard, Customized Drawing
Thread	Metric Coarse, Metric Fine, UNC, UNF, BSW, BSF.
Sizes	M3-M12Metc
Finish	Plain/Copper Plating/others
Price	0.03usd/pcs-0.50usd/pcs
MOQ	Stardard item(Usually little hundred-little thousand)/determined if non-standard

Product Feature

Excellent Material: The interior is made of high-quality carbon steel, which has sufficient mechanical strength and hardness after heat treatment. The thread has strong load-bearing capacity and can be disassembled and reused repeatedly.

Strong conductivity: The surface is electroplated with pure copper, and the copper layer is uniform and dense, ensuring extremely low contact resistance and stable conductivity.

Quality control: Conduct resistance testing through sampling to verify its electrical connection performance.
